Technical Specification
- CNC Bed Milling Machine
- Make-Correa
- Type-A25-40
- Country-Spain
- Control-Heidenhain TNC 355
- Surface table-4500 x 1000 mm
- T slots- 7 x 22 mm
- Distance between T slots-125 mm
- Longitudinal travel(X)-4000 mm
- Cross travel(Y)-1200 mm
- Vertical travel(Z)-1000 mm
- Spindle nose-ISO 50
- Diameter on front bearing- 100 mm
- Number of speeds-∞
- Speed range-20-2500 rpm-t/min.U/min
- Feeds number-∞
- Feeds range-2-5000 mm/min
- Rapid transverse X- 8000 mm/min
- Y-Z-10000 mm/min
- spindle motor- 22 kw
- Feed mptor-37(3)Nm
- Maximum carrying load on the table-7000 KGS
- Machine weight-20000 KGS
- *Vertical traverse 1500(option)
