Technical Specification
- Heavy Duty MIG/MAG Welding Machine
- Make – EWM
- Model – WEGA 500 MG
- Country – Germany
- Machine Type – MIG/MAG Welding Power Source
- Cooling System – Air Cooled
- Output Current Range – 50 – 500 A
- Output Voltage Range – 16.5 – 39 V
- Duty Cycle – 500 A @ 45%, 435 A @ 60%, 335 A @ 100%
- Open Circuit Voltage – 16.5 – 49.5 V
- Input Voltage – 3 Phase, 400 V, 50/60 Hz
- Maximum Connected Load – 27.5 kVA
- Power Factor – 0.95
- Protection Class – IP23
- Insulation Class – H
- Dimensions (L × W × H) – 960 × 560 × 1010 mm
- Machine Weight – Approx. 200 kg
- 2 machines in stock.
